Many people may not be very familiar with the role played by the base of the pneumatic solenoid valve, so Jingzheng will give you a brief summary:
The solenoid valve is composed of solenoid coil and magnetic core, and is a valve body containing one or several holes. When the coil is powered on or off, the operation of the magnetic core will cause the fluid to pass through the valve body or be cut off to change the direction of the fluid. The electromagnetic components of the solenoid valve are composed of fixed iron core, moving iron core, coil and other components; The valve body is composed of slide valve core, slide valve sleeve, spring base, etc. The solenoid coil is directly installed on the valve body, and the valve body is enclosed in the sealing pipe, forming a simple and compact combination.
The solenoid valve base can improve the reliability of the pneumatic system of the machine and reduce its complexity. With the base, it is not necessary to connect the pneumatic pipe on each solenoid valve. Instead, we directly connect the pipe to the base, and the gas will be distributed to each solenoid valve inside the base. Generally, the base is sold in the form of 3 or 6 solenoid valves.
